Yu chai YC6B125-T20 diesel engine, higher power and reliability. Hydrodynamic transmission, three-element and single stage torque converter, high reliability, easy maintenance. Hangzhou Advance Gearbox Group BS428 powershift transmission, high efficiency and easy maintenance
Yu chai YC6B125-T20 diesel engine, higher power and reliability.
Hydrodynamic transmission, three-element and single stage torque converter, high reliability, easy maintenance.
Hangzhou Advance Gearbox Group BS428 powershift transmission, high efficiency and easy maintenance.
Gear-shift controlled by flexible shaft makes operation more flexible and reliable.
Single lever pilot control system, comfortable and flexible operation.
Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
Air over hydraulic disks on four wheel brakes.
Working device with automatically levelling ability at high position.
Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
Integral, luxury instrument board.
New, luxury cabin.
|
项 目 Item |
参 数 |
项 目 |
参 数 |
|
额定铲斗容量 |
1.7 m3 |
最小转弯半径（后轮外侧） |
5160mm |
|
额定载重量 |
3000 kg |
转向角度 |
左右各35º |
|
卸载高度 |
3050 mm |
最小离地间隙 |
410mm |
|
卸料距离 |
1105 mm |
轴距 |
2600mm |
|
动臂提升时间 |
5 .5S |
轮距 |
1800mm |
|
|
|
发动机型号 |
Yu chai YC6B125-T20 |
|
最大行驶速度 |
38km/h |
发动机功率 |
92kW/2200rpm |
|
最大掘起力 |
120 kN |
轮胎规格 |
17.5-25 |
|
最大牵引力 |
90 kN |
外形尺寸（长*宽*高） |
7090*2425*2150mm |
|
最大爬坡能力 |
30° |
整机工作重量 |
9800kg |
Optional: Weichai DEUTZ Dies
