Product introduction：

Reach stacker is designed for 20 feet and 40 feet international container, it is mainly used for container

 stack and terminals, heap of factory level transport. Compared with the forklift, it is flexible, convenient

operation, good stability, wheel pressure is low, stacking layer number is high, the high utilization

of pile factory, etc. Operation can be carried out across the box. Especially used for small and medium sized port, railway station and highway secondary station of container loading and unloading of

technical secondary school, also can be used in the large container terminals as a auxiliary equipment.

Product parameter：

Chassis：high strength self made, 28*9-15 tyre、700-12 tyre

Power system：Anhui Quanchhai QC190G-202 diesel engine、YQXD30A gear box

                       Abhui heli steering bridge、driving axle（hydraulic）

Arm：4m*3 hexagon system、two or three asynchronous telescopic arm

Hydrauli system：A single set of independent operation integrated hydraulic valve group (compound can be realized)

Lifting structure：Yining hydraulic winch

Rotating structure：wheeled Rotating structure

Braking system：hydraulic breaking

Hydrauli ccooling system：Aluminum forced air-cooled radiator,water cooling

Block：4T two skidway

Max.lifting weight：3000kg

Max.lifting height：11.85m

reach stacker picture：
