8 tons of excavator hydraulic system, one of the world's most advanced Japanese Toshiba system can be adjusted according to the load size of main pump output flow, match the engine power output, overloading operations to provide maximum output flow in order to improve the working efficiency; Fine work by negative flow control pump output flow in a suitable range, improve the fuel economy. Comprehensive upgrade driver chamber, handrails box, air conditioning, bring brand-new operation experience, powerful, leading techno
8 tons of excavator hydraulic system, one of the world's most advanced Japanese Toshiba system can be adjusted according to the load size of main pump output flow, match the engine power output, overloading operations to provide maximum output flow in order to improve the working efficiency; Fine work by negative flow control pump output flow in a suitable range, improve the fuel economy. Comprehensive upgrade driver chamber, handrails box, air conditioning, bring brand-new operation experience, powerful, leading technology, Ⅱ emissions reach Europe standard, working efficiency is higher. Elaborate equipment of high strength chassis and enhanced performance in heavy load conditions is especially outstanding, guarantee the durability and reliability of the machine, equipped with 0.34 m3 big dipper capacity at the same time, improves the working efficiency effectively.
type | DLS880-8B | unit |
weight | 7.8 | ton |
bucket capacity | 0.2-0.37 | m³ |
engine type | CUMMINS B3.3 | |
power | 45/2200 | kw/r/min |
speed | 5.1/2.7 | km/h |
rotate speed | 10 | r/min |
grabeability | 70 | % |
bucket digging force | 52.7 | KN |
ground pressure | 30 | KPa |
max flow | 154 | L/min |
fuel tank capacity | 130 | L |
hydraulic tank capacity | 56 | L |
maximum digging height | 7165 | mm |
maximum Dumping Height | 5068 | mm |
maximum digging depth | 4038 | mm |
maximum vertical wall digging depth | 3505 | mm |
least radius of gyration | 1795 | mm |
total length | 6100 | mm |
total width | 2198 | mm |
total height(Movable arm top) | 2515 | mm |
total height(cab roof) | 2680 | mm |
movalbe arm length | 3710 | mm |
bucket rod length | 1650 | mm |
