Welding work station is the latest product developed based on former model. Engine , generator and hydraulic pump are connected directly which features of simple transmission structure and high reliability. Multifunctional digital display meter display apparent overall working conditions. Front double pedal traveling operation, which makes the operation more simple and convenient.
Welding work station is the latest product developed based on former model. Engine , generator and hydraulic pump are connected directly which features of simple transmission structure and high reliability. Multifunctional digital display meter display apparent overall working conditions. Front double pedal traveling operation, which makes the operation more simple and convenient.
1 .Engine , generator and hydraulic pump are connected directly which features of simple transmission structure and high reliability.
2.Reasonable overall arrangement of center of gravity, and high stability.
3.Multi-functional digital meter displays apparent overall working conditions.
4.Front double pedal traveling operation, handle is placed in the cab which makes the operation more simple and convenient.
5.Split housing is convenient for repair & maintenance.
|
Items 项目名称 |
Main parameters 主要参数 |
||
|
Model 产品型号 |
HQ100 |
HQ125 |
|
|
Dimensions (L×W×H) mm 外形尺寸（长*宽*高） |
5850 * 2470 * 3050mm |
5850 * 2470 * 3050mm |
|
|
Overall weight(approx.) t 整机质量 |
9.65t |
10.17t |
|
|
Average ground pressure kPa 接地比例 |
28.6 kPa |
30.15kPa |
|
|
Max. climbing capability ° 最大爬坡角度 |
25° |
||
|
Max. traction force kN 最大牵引力 |
91 kN |
||
|
Travelling speed km/h 行驶速度 |
Double speed , gear I 0 ~ 2.9 gear II 0 ~ 4.6 |
||
|
Engine 发动机 |
Model 型号 |
6BTA5.9-C170 |
6BTAA5.9-C180 |
|
Rated power/ rotating speed 额定功率 |
127kW/2000rpm |
132kW/2200rpm |
|
|
Min. fuel consumption g/kW·h 最低燃油消耗功率 |
204 g /kW · h |
208 g /kW · h |
|
|
Generator 发电机 |
Model 型号 |
UCI 274C 1 |
UCI274E2 |
|
Rated capacity kVA 额定容量 |
100kVA (80kW) |
140kVA(112kW) |
|
|
Rated voltage V 额定电压 |
380/220 V |
380/220 V |
|
|
Rated frequency Hz 额定频率 |
50Hz |
50Hz |
|
|
Crane 起重机 |
Max. lifting capacity KN·m 最大起重力 |
78.4KN · m |
|
|
Max. working range m 最大工作幅度 |
7.8 ( from crane turning center ) |
||
|
Max. lifting height m 最大起升高度 |
9m |
||
|
Turing type 回转形式 |
full 360°turing |
||
|
Luffing angle(degree) 变幅角度 |
1 ~ 80° |
||
|
Electrical control 电器 |
Electrical leakage protection 漏电保护 |
yes |
|
|
cabinet |
Nos.of external plug 外接插头数量 |
2 380V total 10kW ,2 220V total 2.2kW |
|
|
Air compressor ( optional ) 空压机 |
Type 形式 |
Electrical driving 2 stage piston type |
|
|
Pressure Mpa 压力 |
1.6 MPa |
||
|
Flow L/min 流量 |
800 L /min |
||
|
Gas cylinder(optional) 气缸 |
Type 形式 |
Manual pump driving hydraulic cylinder up and down |
|
|
Nos. of carried cylinder |
3 or 4 |
||
