Electric forklift is powered from battery , drive motor and hydraulic system, so as to realize travel and handling.
Electric forklift GN25H summary
Electric forklift, compared with diesel forklift, has the advantages of no pollution, easy operation, energy efficient, the operator's work strength to light many relative tointernal combustion forklifts, electric steering system, speed control system,hydraulic control system and brake system are controlled by electrical signals, greatly reduce the labor intensity of the operators, thus to improve the work efficiency and the accuracy of work.
Electric forklift GN25D parameter
summary |
model |
GN25SH |
Unit |
||
rated capacity |
2500 |
Kg |
|||
load center |
500 |
mm |
|||
power type |
battery |
||||
dimention |
lifting height |
3000 |
mm |
||
door frame Angle(front/rear) |
6/12 |
deg |
|||
outline dimention |
total length |
3445 |
mm |
||
total width |
1160 |
mm |
|||
total height |
2130 |
mm |
|||
Min. turn radius |
2050 |
mm |
|||
performance |
Max.travle speed(with load/without load) |
12/14 |
Km/h |
||
Max.lifting speed(with load/without load)) |
265/435 |
mm/sec |
|||
gradeability |
15 |
% |
|||
self weight |
4200 |
kg |
|||
chassis |
tire |
front |
7-12-12PR |
|
|
rear |
18*7-8-14PR |
|
|||
axle base |
1500 |
mm |
|||
battery |
voltage/Vol. |
48/600 |
V/Ah |
||
Motor and controller |
rive motor power |
9.1(AC) |
Kw |
||
pump motor power |
8.6(DC) |
Kw |
|||
control type |
MOS pipe |
Kw/rpm |
