整机性能Specifications

额定载荷Rated operating capacity(kg)

700

倾翻载荷Tipping load(kg)

1400

铲斗容量Bucket capacity(m3)

0.4-0.5

机器操纵质量Operationg weight(kg)

3000

行驶速度Max. travel speed(km/h)

12

工作流量Hydraulic pump flow(L/min)

75

油箱容量Fuel tank capacity(L)

70

轮胎型号Tires

10/16.5NHS

整车尺寸Overall dimensions(mm)

3350×1720×2050

整机参数Dimensions

最大操作高度Height at maximum extension(mm)

3980

铰接销高度Height to bucket hinge pin(mm)

3080

带斗宽度Width with bucket(mm)

1730

轮距Track width(mm)

1450

轴距Wheelbase(mm)

991

离地高度Ground clearance(mm)

180

倾倒角Dump angle

30°

倾倒高度Dumping height(mm)

2380

接近角Rollback at ground

26°

离去角Angle of departure

20°

发动机Engine

型号Maker/Model

新柴490

功率转速Net power

51hp/2500rpm

类型Type                    直喷直列水冷四冲程柴油机

4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine

排量Displacement(L)

2.7

标准配置Standard

封闭驾驶室Deluxe enclosed operator cab

手动控制Hand control system(Mechanical type)

标准铲斗Standard bucket

辅具输出装置Auxiliary hydraulic couplers

可选配置Optional

低温起动装置

Prehest starting assist system for extreme cold weather

内置暖风

Cab fitted with a heater as standard

冷暖空调

Air conditioner

双速系统

2-speed transmission system

辅具Attachments：
挖掘机
