整机性能Specifications

额定载荷Rated operating capacity(kg)

1500

铲斗容量Bucket capacity(m3)

0.6-0.7

机器操纵质量Operationg weight(kg)

4000

行驶速度Max. travel speed(km/h)

12/18

工作流量Hydraulic pump flow(L/min)

75/130

油箱容量Fuel tank capacity(L)

85

整车尺寸Overall dimensions(mm)

3385×1850×2025

整机参数Dimensions

铰接销高度Height to bucket hinge pin(mm)

2920

带斗宽度Width with bucket(mm)

1850

履带宽度(mm)

320

履带地面长度(mm)

1500

离地高度Ground clearance(mm)

200

发动机Engine

型号Maker/Model

潍柴道依茨   Deutz /东风康明斯Cummins

功率转速Net power

100hp/2500rpm

类型Type

直喷直列水冷四冲程柴油机
4 Cylinder in-line, Water cooled, 4 stroke,Diesel engine

排量Displacement(L)

3.9

标准配置Standard

标准铲斗Standard bucket

开式驾驶室Open-type operator cab

液压伺服控制(单手行驶)Hydraulic joystick controls

辅具输出装置Auxiliary hydraulic couplers

可选配置Optional

全封闭驾驶室空调Enclosed operator cab with A/C

大流量液压工作系统High-flow hydraulic system

低温起动装置Prehest starting assist system for extreme cold weather
