整机性能Specifications

额定载荷Rated operating capacity(kg)

1200

倾翻载荷Tipping load(kg)

2400

铲斗容量Bucket capacity(m3)

0.7

机器操纵质量Operationg weight(kg)

3560

行驶速度Max. travel speed(km/h)

12

工作流量Hydraulic pump flow(L/min)

120-144

油箱容量Fuel tank capacity(L)

90

轮胎型号Tires

12/16.5NHS

整车尺寸Overall dimensions(mm)

3560×1900×2150

整机参数Dimensions

最大操作高度Height at maximum extension(mm)

4070

铰接销高度Height to bucket hinge pin(mm)

3150

带斗宽度Width with bucket(mm)

1900

轮距Track width(mm)

1500

轴距Wheelbase(mm)

1185

离地高度Ground clearance(mm)

260

倾倒角Dump angle

40°

倾倒高度Dumping height(mm)

2450

倾倒前伸Maximum reach(mm)

710

接近角Rollback at ground

26°

离去角Angle of departure

20°

发动机Engine

型号Maker/Model

潍柴道依茨   Deutz/东风康明斯Cummins

功率转速Net power

100hp/2500rpm

类型Type

直喷直列水冷四冲程柴油机
4Cylinder in-line, Water cooled, 4 stroke,  Diesel engine

排量Displacement(L)

3.9-4.2

标准配置Standard

标准铲斗

Standard bucket

封闭驾驶室

Enclosed operator cab

液压伺服控制(单手操纵行走)

Hydraulic joystick controls

辅具输出装置

Auxiliary hydraulic couplers

可选配置Optional

大流量液压工作系统

High-flow hydraulic system

低温起动装置

Prehest starting assist system for extreme cold weather

内置暖风

Cab fitted with a heater as standard

冷暖空调

Air conditioner

双速系统

2-speed transmission system
